Perimter Secuirty 358 Anti-Climb Fence Panel
Product Name: 358 Anti-Climb Fence For Perimter Secuirty
Clour :Moss Green(RAL6005); Grey(RAL7021),Black(RAL9005) or as request.
Post type:RHS80x60,SHS80x80,C type 80×60 ,IPE100x68
Panel type:2D/3D/2D plus,Flat or with curves
Posts & Fixings: High Security 358 perimeter fencing is installed with post and clamp bar , fixed with bolts, washers and nuts .
Certification: ISO9001, GB/T28001-200, ISO14001
Ask for quoteDescription
Anti-Climb Fence also called high security fence, anti-cut fence, “PRISON MESH” or 358 wire mesh fence. This fence is welded from 4mm hot-dipped galvanized wire, weld strength is a minimum of 50% to steel strength.’358′ comes from its measurements 3″ × 0.5″ × 8 gauge which equates to approx. 76.2 mm × 12.7 mm × 4 mm in metric. this security fence system is the first line of defense in high security fencing systems; by added anti-climb fence spikes to the top you can enjoy ultimate security.
Advantages
- More small openings, no toe or finger holds.
- Robust wire and welded joints make cutting very difficult by bolt cutters and wire cutters.
- Single panel heights can be supplied of up to 7 meters
Specs
| Wire Diameter | 3mm(10 gauge),4mm (8 gauge) |
| Mesh Aperture | 75mm x 12.5mm |
| Vertical wire pitch | 10mm to 76.2mm |
| Horizontal wire pitch | 12.7mm to 200mm |
| Height | 1.8m, 2m, 2.4m, 2.7m, 3m, |
| Width | 2m, 2.4m, etc. |
| Square post | 50x50mm, 60x60mm, 80x80mmm, 100x100mm, etc. |
| Surface treatment | Electro galvanized, Hot-dipped galvanized, Powder coated, PVC coated |
| Color | RAL6005 Green; RAL9005 Black, or as your request. |
| Top | Barbed wire, Razor wire can be used on top to make it higher security |
Post Options
| Post style | Square post | IPE post | Rectangle post | C post with flat bar |
| Size A(mm) | 60×60 | 100×55 | 60×80 | 60×80 |
| Size B(mm) | 80×80 | 100×68 | 80×100 | 80×100 |
| Size C(mm) | 100×100 | 120×74 | 100×150 | 100×150 |
| Wall thickness | 1.2-1.5mm | 1.2-2.0mm | 2.5-5.0mm | 2.0-5.0mm |
Galvanized Anti-Climb Fence Surface
PVC Coted Anti-Climb Fence Surface
V -Bend Anti-Climb Fence Panel
Anti-Climb &Anti-Cut
Installation Style
Packaging &Shipping
1. Fence panel: on pallet.
2. Post: packed in plastic bag, and then wrapped by air bubble film
3. Clips or rain hat with cartons.
Application
Anti climbing fencing is ideally suited for electronic alarm and detection systems ,widly used in high security places ,such as Military, airports, secure units and prison.
